DWH

Find the right product solutions

DWH – Potting & Casting epoxy

DWH grades are designed for static fits in machine assembly, they do not include low-friction fillers. DWH resins are produced in various viscosities and have more than 80% metallic fillers. DWH is used to mold static machine components in-place and to eliminate expensive machining and scraping. It can also be used as repair material for maintenance. Its ability to mold to any shape makes it possible to shim with 100% contact.

Typical Applications

all kinds of machine tools
joints, grinding spindles, keyways
guideways, bearing supports and flanges
machine beds – bearings and bushings

Product Properties

high precision true to measurement
high bearing forces up to 120 N/mm2 (static)
excellent damping and 100% forcefit
100% force transfer,
excellent adhesion
nearly no aging or weathering
perfect exactness to the micron
without costly machining or final working

Product Description

DWH is a fine adjustment coating system for connecting surfaces in machine elements and machine tools, omitting the expensive machining by the proven molding technology.

Benefits

DWH molds micron-exact in place making an exact copy of the surfaces the*** easy way.

The user can decide whether they want a firm adhesion or one that can easily be dismantled. When necessary for this, Separator is applied before molding.

DWH can be used for all metal elements which need to be long term, exact, resistant, adjusted, fixed & centered. This will improve stiffness

guide pins and bushings are molded in place
optimizing the stiffness
screw holes are closed
machine elements are centered
element groups are fixed

All that without machining…

… and in 1 step with best damping properties and high cost savings guaranteed by the DIAMANT Fine Adjustment Coating System DWH for more than 5 decades, and not only in machine engineering.

More Benefits:

DWH can be used in place without special knowledge for any type of machine element.

And it is that easy:

roughen & clean adhesion surfaces
align
mix DWH
apply or inject
leave to cure and…
ready! exact to the micron.

To Find the Grams of Moglice Required:

Example: 48″ Length x 5″ Width x .062″ Thickness = 14.88 cubic inches x 31 (FL) = 461 Grams of DWH Needed

Machine Tool Way Rebuilding

Click the button below to download the Machine Tool Way Rebuilding Handbook. Requires Adobe Acrobat Reader to view.

Download Now!
